Key Features
- Measures DC voltages up to 25V
- Safe voltage divider output for microcontroller ADC
- 1-channel analog input
- High accuracy and low noise design
- Compact, easy-to-use module
- Ideal for battery monitoring, solar systems, robotics, and DIY electronics
Technical Specifications
| Parameter | Value |
|---|---|
| Input Voltage Range | 0–25V DC |
| Output Voltage | 0–5V (scaled) |
| Divider Ratio | 5:1 |
| Interface | Analog output |
| Accuracy | ±1% (typical) |
| Output Pins | VCC, GND, OUT |
Applications
- Battery level monitoring
- Power supply measurement
- Solar panel voltage monitoring
- Robotics and automation
- IoT power tracking
Package Includes
- 1 × Voltage Sensor Module (0–25V)
