Key Features
- Fixed 5 V DC regulated output
- Surface mount (SMD) package for compact PCB designs
- Low dropout voltage for efficient regulation
- Built‑in thermal shutdown and short‑circuit protection
- Minimal external components required
- Ideal for low‑power embedded circuits
- Compatible with 5 V logic systems
Technical Specifications
- Type: Linear Voltage Regulator (Fixed)
- Model: 78M05 SMD
- Output Voltage: 5 V DC ±4%
- Input Voltage Range: ~7 V to 35 V DC (typical)
- Output Current: Up to 500 mA (varies with thermal conditions)
- Dropout Voltage: Typically ~2 V
- Protection: Thermal shutdown, current limit
- Package: SMD (surface mount)
- Mounting: PCB surface mount
- Operating Temperature: -40 °C to +85 °C (typical)
Applications
- Power regulation for microcontrollers (Arduino, ESP32, etc.)
- Embedded systems requiring stable 5 V supply
- Sensor modules and interface circuits
- Consumer electronics requiring 5 V logic
- Communication modules and low‑power devices
- DIY and prototyping power supplies
Package Includes
- 1 × 78M05 SMD Voltage Regulator (5 V)
