Key Features
- Measures AC & DC current up to ±30A
- Hall-effect isolation for safe measurement
- Analog voltage output proportional to sensed current
- Operates at 5V, fully compatible with Arduino, ESP32, STM32, Raspberry Pi
- High sensitivity and low noise output
- Onboard filter capacitor for smooth readings
Technical Specifications
| Specification | Details |
|---|---|
| Model | ACS712ELC-30A |
| Current Range | ±30A |
| Sensitivity | ~66 mV/A |
| Output Type | Analog |
| Operating Voltage | 5V |
| Isolation Voltage | 2100 VRMS |
| Bandwidth | 80 kHz |
| Response Time | 5 µs |
| Pins | VCC, GND, OUT |
Applications
- High-current AC/DC measurement
- Solar power monitoring
- Inverters and power supplies
- Motor control systems
- Battery management and energy meters
- Industrial IoT sensing devices
Package Includes
- 1 × ACS712 30A Current Sensor Module
