Current to Voltage Converter Module

Key Features

• Converts current input into stable voltage output
• Ideal for 4–20 mA and other current loop signals
• High accuracy and linear conversion
• Low noise and stable performance
• Compatible with microcontrollers and ADC modules
• Compact design for easy PCB integration
• Provides electrical isolation (on some variants)

Technical Specifications

• Type: Current to Voltage (I/V) Converter
• Input Current Range: 0–20 mA / 4–20 mA (variant dependent)
• Output Voltage Range: 0–5 V / 0–10 V (variant dependent)
• Conversion Method: Precision resistor and op-amp based
• Supply Voltage: 5 V to 24 V DC (module dependent)
• Accuracy: ±0.5% (typical)
• Linearity: High linear response
• Mounting: PCB module / Through-hole terminals

Applications

• Interfacing 4–20 mA sensors with microcontrollers
• Industrial automation and PLC systems
• Data acquisition and monitoring systems
• Process control instrumentation
• Sensor signal conditioning circuits
• DIY and educational electronics projects

Package Includes

• 1 × Current to Voltage Converter Module
