Key Features
- 2.4 GHz Quad-Core 64-bit ARM Cortex-A76 CPU for powerful processing
- 4GB LPDDR4X RAM enables smooth multitasking and complex workloads
- Dual 4K @ 60Hz HDMI output with improved video performance
- PCIe 2.0 ×1 interface for high-speed add-ons like SSDs
- Faster microSD performance with SDR104 support
- Gigabit Ethernet + Wi-Fi 6 ready via add-on module
- GPIO compatibility with previous Raspberry Pi boards
Technical Specifications
- Processor: Broadcom BCM2712, Quad-Core Cortex-A76 @ 2.4 GHz
- RAM: 4GB LPDDR4X-4267
- Video Output: 2 × micro-HDMI (up to 4K @ 60Hz dual display)
- GPU: VideoCore VII, improved graphics acceleration
- Storage: MicroSD slot supporting SDR104; PCIe via FPC connector
- Connectivity:
- USB Ports: 2 × USB 3.0, 2 × USB 2.0
- Ethernet: 1 × Gigabit Ethernet
- Wireless: Wi-Fi 6/Bluetooth (via external module, not included by default)
- Camera/Display: 2 × CSI/DSI ports supporting simultaneous cameras/displays
- Power Input: USB-C, 5V 5A recommended
- GPIO: 40-pin header, backward compatible
- Dimensions: 85 mm × 56 mm (approx.)
Applications
- High-performance robotics & automation
- Edge AI & machine learning models
- Network appliances, home servers & SSD-based NAS
- 4K multimedia & dual-display desktops
- Camera-based vision systems
- Education, prototyping & research
Package Includes
- 1 × Raspberry Pi 5 Model – 4GB RAM
