Thermoelectric Cooler – TEC1-12715 (Peltier Module)

Key Features

• Solid-state cooling with no moving parts
• Capable of both cooling and heating (polarity dependent)
• High current capacity for improved cooling performance
• Compact and lightweight ceramic construction
• Reliable and maintenance-free operation
• Easy integration into custom thermal systems

Technical Specifications

• Type: Thermoelectric Cooler (Peltier Module)
• Model: TEC1-12715
• Operating Voltage: 12 V DC (typical)
• Maximum Current (Imax): 15 A
• Maximum Power: ~180 W (approx.)
• Maximum Temperature Difference (ΔTmax): ~65°C
• Hot Side Temperature: Up to 90°C (with proper heat sinking)
• Module Size: ~40 × 40 × 3.8 mm
• Leads: Red & black wire
• Polarity Sensitive: Yes

Applications

• Electronic cooling and thermal management
• Mini refrigerators and cooling plates
• Laser diode and sensor temperature control
• CPU, power electronics, and enclosure cooling
• DIY experiments and educational projects

Package Includes

• 1 × TEC1-12715 Thermoelectric Cooler Module
