Toggle Switch DPDT

In stock

(Double Pole Double Throw On-On / On-Off-On Configuration)

A DPDT Toggle Switch is a mechanical switching device that controls two independent circuits simultaneously. Each pole can connect to one of two outputs, giving it the ability to reverse polarity, change signal paths, or switch between two different loads. This makes it widely used in robotics, motor direction control, DIY electronics, and power switching applications.

Categories: Switch

Brands:

Key Features

• Controls two separate circuits at the same time
• Available in On-On or On-Off-On configurations
• Ideal for motor direction reversal (H-bridge style switching)
• Sturdy toggle lever ensures reliable tactile switching
• Suitable for low to moderate power applications

Technical Specifications

• Switch Type: DPDT (Double Pole Double Throw)
• Contact Configuration: 2 poles × 2 throws
• Operating Voltage: Typically up to 250V AC / 30V DC (model dependent)
• Current Rating: 6A–15A depending on model
• Contact Resistance: ≤ 20 mΩ (approx.)
• Mounting Style: Panel mount with threaded bushing
• Terminals: 6 terminals (2 poles × 3 terminals each)
• Operating Temperature: −10°C to +85°C (typical)

Applications

• DC motor forward/reverse rotation
• Switching between power sources or loads
• Audio routing and signal control
• Robotics and automation projects
• Power distribution panels
• DIY prototyping and testing setups
