Arduino CNC Shield

Key Features

• Compatible with Arduino UNO
• Supports A4988, DRV8825, or similar stepper motor drivers
• Control up to 4 stepper motors (X, Y, Z, and A axis)
• Provides limit switch connections for precise movement
• Easy stackable design for DIY CNC and 3D printer projects

Technical Specifications

• Board Type: CNC Shield V3
• Stepper Driver Compatibility: A4988 / DRV8825
• Power Supply: 12–36V (depending on motor driver)
• Axis Support: 4-axis (X, Y, Z, A)
• Control Interface: Arduino UNO compatible
• Limit Switch Support: Yes (endstops)

Applications

• DIY CNC milling and engraving machines
• 3D printer motion control
• Laser engraving and cutting
• Robotics and automated systems
• Educational and prototyping projects

Package Includes

• 1 × Arduino CNC Shield V3
