Diode BY399

Key Features

• High reverse voltage rating up to 2000V
• Forward current handling up to 3A
• Fast recovery time (~200 ns) for high-frequency applications
• Robust axial-leaded package for easy PCB mounting
• Ideal for high-voltage rectification and power conversion

Technical Specifications

• Type: Fast Recovery Rectifier Diode
• Maximum Repetitive Reverse Voltage (V_RRM): 2000 V
• Forward Current (I_F Avg): 3 A
• Surge Forward Current (I_FSM): 80 A (8.3 ms single half-sine)
• Forward Voltage Drop (V_F): ~1.3 V at 3 A
• Reverse Recovery Time (t_rr): ~200 ns
• Package: DO-201 / Axial

Applications

• High-voltage rectifier circuits
• SMPS input rectification
• Voltage multipliers
• Industrial power control circuits
• HV capacitor charging circuits

Package Includes

• 1 × BY399 Diode (Axial Leaded)
