Multi-Tap Step-Down Transformer – Multiple Secondary Options (500 mA / 1 A)

Key Features

• Multiple selectable secondary voltage outputs
• High reliability and stable performance
• Suitable for low current power supplies and circuits
• Laminated steel core for low noise and efficiency
• Class-rated insulation for safety
• Standard pinout for easy PCB or chassis mounting

Available Variations

• 0–6 V / 500 mA
• 6–0–6 V / 500 mA (center-tapped output)
• 0–9 V / 500 mA
• 9–0–9 V / 500 mA (center-tapped output)
• 12–0–12 V / 500 mA (center-tapped output)
• 0–15 V / 500 mA
• 15–0–15 V / 500 mA (center-tapped output)
• 18–0–18 V / 500 mA (center-tapped output)
• 24–0–24 V / 1 A (center-tapped output)

Technical Specifications

• Type: Step-Down Power Transformer
• Primary Voltage: 230 V AC (50 Hz)
• Secondary Voltage Options:
  • Single winding: 0–6 V, 0–9 V, 0–15 V
  • Center-tapped: 6–0–6 V, 9–0–9 V, 12–0–12 V, 15–0–15 V, 18–0–18 V, 24–0–24 V
• Current Rating:
  • 500 mA (for up to 18–0–18 V variants)
  • 1 A (for 24–0–24 V variant)
• Power Rating: Varies by version (e.g., ~30 VA for 6 V, ~48 VA for 12 V, ~120 VA for 24 V)
• Core Type: Laminated iron core
• Mounting: PCB / Chassis mount (model dependent)
• Insulation: Class A/B insulation system

Applications

• Bench power supplies (after rectification and regulation)
• Low voltage AC applications
• Analog circuits and audio electronics
• Educational and training kits
• Embedded power supply modules
• DIY and hobby electronics

Package Includes

• 1 × Step-Down Transformer (selected voltage variant)
