Key Features
- Compact metal gearbox design for durability and high torque output
- Available in multiple RPM options depending on gearbox ratio (typical: 30–1000 RPM)
- Compatible with Arduino, motor drivers, and control boards
- Efficient 3V–6V DC operation
- Easy integration into robot chassis, wheels, and gear assemblies
- Ideal for precision movement and lightweight mechanisms
Technical Specifications
- Motor Type: Brushed DC motor with metal gearhead
- Model: N20 gear motor
- Operating Voltage: 3V to 6V DC (Nominal 6V)
- Gear Ratios Available: typically 10:1 to 1000:1 (depending on torque and speed requirement)
- No-Load Speed (6V): approx. 30 to 1000 RPM (model dependent)
- Stall Torque (6V): approx. 0.3 – 2.5 kg·cm (model dependent)
- Shaft Type: D-shaped metal shaft
- Shaft Length: commonly 10 mm
- Motor Body Size: approx. 12×10×26 mm (excluding shaft)
- Mounting: 2× screw holes for bracket or chassis connection
Applications
- Small robots and AGV systems
- Line follower & maze solver robots
- Smart locks and automated latches
- Camera sliders & precision mechanisms
- Mini conveyor systems
- Pan-tilt systems, RC models & toys
- Educational STEM and prototyping kits
Package Includes
- 1 × N20 Mini Metal Gear Motor (RPM as per your selection/order)
