Split Core Current Transformer – SCT-013 (100A / 50mA)

Key Features

• Non-invasive split-core clamp design
• Measures AC current up to 100 A
• Electrical isolation for safe current sensing
• Compact and lightweight enclosure
• High accuracy and stable output
• Easy integration with energy meters and microcontrollers

Technical Specifications

• Type: Split Core Current Transformer
• Model: SCT-013
• Rated Input Current: 0–100 A AC
• Rated Output: 50 mA AC
• Turns Ratio: 2000:1 (typical)
• Operating Frequency: 50 / 60 Hz
• Accuracy: ±1% (typical)
• Dielectric Strength: ≥3 kV AC
• Operating Temperature: −25°C to +70°C
• Output Connector: 3.5 mm jack (model dependent)
• Mounting: Clip-on / clamp-on

Applications

• Energy and power monitoring systems
• Smart meters and IoT energy projects
• AC load measurement
• Industrial and residential power analysis
• Arduino, ESP, and Raspberry Pi based projects

Package Includes

• 1 × SCT-013 Split Core Current Transformer (100A / 50mA)
