Split Core Current Transformer – SCT-013 (10A / 1V)

Key Features

• Non-invasive split-core clamp design
• Measures AC current up to 10 A
• Direct voltage output (1 V AC at rated current)
• Built-in burden resistor for easy interfacing
• High electrical isolation and safe operation
• Compact, lightweight, and easy to install

Technical Specifications

• Type: Split Core Current Transformer
• Model: SCT-013
• Rated Input Current: 0–10 A AC
• Rated Output: 1 V AC (at 10 A)
• Output Type: Voltage output (burden resistor built-in)
• Operating Frequency: 50 / 60 Hz
• Accuracy: ±1% (typical)
• Dielectric Strength: ≥3 kV AC
• Operating Temperature: −25°C to +70°C
• Output Connector: 3.5 mm jack (model dependent)
• Mounting: Clip-on / clamp-on

Applications

• Low-current energy monitoring
• Smart meters and power measurement systems
• Arduino, ESP32, and Raspberry Pi projects
• AC load monitoring in appliances
• Educational and DIY electronics projects

Package Includes

• 1 × SCT-013 Split Core Current Transformer (10A / 1V)
