Inductive Proximity Sensor – JG-GI18-08N1 (M18, 8 mm, NPN-NO, 6–36 V DC)

Key Features

• 8 mm sensing distance for reliable metal detection
• NPN Normally-Open (NO) output compatible with PLCs and microcontrollers
• Wide operating voltage (6–36 V DC) for flexible industrial usage
• Durable nickel-plated M18 housing for mechanical and environmental protection
• LED indicator for detection status and troubleshooting
• Short-circuit and overload protection for safe operation

Technical Specifications

• Model: JG-GI18-08N1
• Sensor Type: Inductive proximity (metal detection)
• Output Type: NPN, Normally-Open
• Sensing Distance: 8 mm (ferromagnetic target)
• Operating Voltage: 6–36 V DC
• Max Output Current: ≤ 200 mA
• Switching Frequency: ≥ 800 Hz
• Protection: Short-circuit and overload
• Indication: LED status indicator
• Housing Material: Nickel-plated brass, M18 threaded body
• Mounting: Lock-nut included
• Cable Length: Approx. 1.2 m (model dependent)
• Operating Temperature: −25°C to +70°C

Applications

• Industrial automation & production line equipment
• CNC machines & robotic arm position detection
• Metal detection on conveyor systems
• End-limit or proximity sensing in industrial machinery
• Counting, sorting, and packaging processes
• Robotic motion feedback with metal targets

Package Includes

• 1 × JG-GI18-08N1 Inductive Proximity Sensor (M18, 8 mm, NPN/NO)
• 2 × Mounting Lock Nuts
