Inductive Proximity Sensor – JG-GI18-05N1 (M18, 5 mm, NPN/NO, DC 6–36 V)

Key Features

• 5 mm stable sensing distance for accurate metal detection
• NPN Normally-Open (NO) output suitable for PLC and microcontroller interfacing
• Wide operating voltage (6–36 V DC) for flexible industrial use
• Durable nickel-plated M18 cylindrical housing for mechanical protection
• LED indication for quick detection and status monitoring
• Short-circuit and overload protection for safe operation

Technical Specifications

• Model: JG-GI18-05N1
• Sensor Type: Inductive proximity, metal detection
• Output Type: NPN, Normally-Open
• Sensing Distance: 5 mm (ferromagnetic target)
• Operating Voltage: 6–36 V DC
• Output Current: ≤ 200 mA
• Response Frequency: ≥ 800 Hz
• Protection: Short-circuit, overload
• Indication: LED status indicator
• Housing Material: Nickel-plated brass
• Mounting: M18 threaded body with lock nuts
• Cable Length: Approx. 1.2 m (model dependent)
• Operating Temperature: −25°C to +70°C (approx.)

Applications

• Industrial automation & factory equipment
• CNC machines & robotic arms
• Metal detection on conveyor systems
• Position sensing & end-limit detection
• Counting, sorting & packaging machines
• Speed/rotation feedback with metal targets

Package Includes

• 1 × JG-GI18-05N1 Inductive Proximity Sensor (M18, 5 mm, NPN/NO)
• 2 × Mounting Lock Nuts
