Key Features
- Voltage-dependent resistor for surge protection
- Rapid response to transient voltage spikes
- Radial leaded through-hole design for PCB mounting
- High energy absorption capacity
- Stable performance over a wide temperature range
- Suitable for both AC and DC applications
Technical Specifications
- Type: Metal Oxide Varistor (MOV)
- Model: 14D147K
- Varistor Voltage (V<sub>V</sub>): 147 V
- AC Voltage Rating: 100 V AC (typical)
- Clamping Voltage: ~255 V (at 50 A surge)
- Maximum Surge Current: 4 kA (8/20 µs waveform)
- Tolerance: ±10%
- Capacitance: ~200 pF
- Operating Temperature: -40 °C to +85 °C
- Mounting: Radial lead through-hole
Applications
- Surge and transient protection for consumer electronics
- Protection of power supplies, inverters, and industrial drives
- Noise suppression and voltage spike absorption
- Electrical and electronic appliances
- DIY electronics and educational projects
Package Includes
- 1 × MOV 14D147K Metal Oxide Varistor
