MOV 14D241K – Metal Oxide Varistor (Surge Protection)

Key Features

• Fast response to transient voltage surges
• High energy absorption capability
• Reliable clamping characteristics
• Radial leaded design for easy PCB mounting
• Stable performance over a wide temperature range
• Suitable for AC and DC power lines

Technical Specifications

• Type: Metal Oxide Varistor (MOV)
• Model: 14D241K
• Varistor Voltage (Vᵥ): 240 V
• AC Voltage Rating: 150 V AC (typical)
• DC Voltage Rating: 200 V DC (typical)
• Clamping Voltage: ~395 V (at 50 A surge)
• Maximum Surge Current: 4.5 kA (8/20 µs waveform)
• Tolerance: ±10%
• Capacitance: ~120 pF (typical)
• Operating Temperature: -40 °C to +85 °C
• Mounting: Radial lead, through-hole PCB

Applications

• Surge protection for power supplies and adapters
• AC mains and DC input protection
• Industrial control systems
• Consumer electronics
• Inverters and UPS systems
• DIY and educational electronics projects

Package Includes

• 1 × MOV 14D241K Metal Oxide Varistor
